Progressive Distributors For Grease

The HBY-23 progressive grease distributor uses stacked lightweight aluminum alloy modules, providing fixed-volume grease supply for 16 lubrication points. Each outlet is equipped with an integrated safety relief valve and visual overpressure indicator rod. An internal centralized overflow channel recycles excess grease back to the pump tank to avoid waste and contamination. Not approved for explosive or hazardous areas, it fits heavy-duty centralized lubrication systems for mining, construction, port machinery and automated production lines. Its compact stacked design saves installation space, and full-point pressure protection prevents system shutdown caused by single-point blockage.

1.Lightweight Aluminum Alloy Stacked Modular Body, Compact Layout

The whole valve body adopts aluminum alloy raw material, greatly reducing self-weight compared to cast iron distributors. Multi-layer stacked split block design realizes 16 outlets in small overall volume, fitting narrow installation spaces of engineering vehicles and port equipment with limited reserved space.

2.Full Outlets Equipped with Independent Safety Relief Valve + Blockage Indication

Each of the 16 lubrication outlets is equipped with a dedicated safety valve and overpressure visible indicator rod. If one friction point pipeline is fully blocked, the safety valve automatically opens to release pressure, so the whole distributor can keep running normally. The protruding indicator rod directly marks the blocked position, allowing maintenance staff to quickly locate faults without circuit detection.

3.Centralized Overflow Oil Return Circuit, Zero Grease Waste & Pollution Avoidance

All safety valve overflow grease converges into an integrated internal flow channel, connected to the lubrication pump oil storage tank through the reserved ZG1/8 return port. No overflow grease drips onto equipment surface, avoiding environmental pollution and raw material waste, ideal for clean production workshops and outdoor heavy machinery.

4.Fixed Precise Quantitative Output, Stable Lubrication for Bearing Components

Fixed 0.35ml single-cycle displacement design, delivering consistent grease volume to bearings each circulation. Effectively prevent insufficient lubrication leading to abrasion or excessive grease causing heat buildup, fully matching standardized bearing lubrication volume requirements of industrial equipment.

1.Full-point Independent Pressure Protection, No System Shutdown from Single Blockage

Unlike ordinary distributors lacking single-point safety valves, HBY-23 configures independent pressure relief for every outlet. Single pipeline blockage will not cut off the oil supply of other lubrication points, effectively reducing equipment downtime loss.

2.Integrated Overflow Recovery Design, Low Operation & Maintenance Cost

Concentrated oil return channel recycles overflow grease back to the oil tank, eliminating regular manual cleaning of waste grease on equipment. Aluminum alloy body features anti-rust surface treatment, longer service life than cast iron distributors under humid port and mine environments.

3.Integrated Stacked Block Structure, Minimal External Leakage Points

Multi-layer blocks locked by uniform hexagon socket screws with built-in O-ring sealing. Fewer external pipe joints compared to split assembled distributors, greatly lowering grease leakage risk and simplifying on-site installation piping.

4.Clear Lubricant Usage Specifications to Extend Valve Service Life

The product strictly forbids grease mixed with graphite, molybdenum disulfide, calcium carbonate, calcium hydroxide and graphene. Hard solid particles will scratch pistons and seal rings and trigger frequent blockage; equipment using graphene grease will only enjoy half the original warranty period.
